2S2P 18650 Battery Holder 電池盒

產品型號：2S2P

上架時間：2020-04-01

產品簡述產品詳情產品視頻留言咨詢

技術參數
產品型號	2S2P 18650 Battery Holder Build-in Protection Circuit Module
產品簡介	Name: 2S2P 18650 Battery Holder Part No. : 18650-2S2P-7.4V PCM: PCM-L02P02-378(2S2P) Overall Size: 84 x 82.5 x 18.6 (mm) Holder Materials: PC Weight: 30g (Cells not included)
主要特點	① Canal ② Contact spring 1 ③ Build in hole ④ Holder ⑤ Contact spring 2 ⑥ Cover
SUMMARY	The holder is specially designed with modern build-in protection circuit module. The feature can guarantee Li-ion battery pack safe in use. It’s flexible and convenient for various customized application. WARNING: Wrong polarity placement may cause dangerous accident in charging and discharging!!!
Protection Circuit Module Specifications	No.	Test Item	Description	Criterion
	1	Voltage	Charging voltage	DC8.4V
	1	Voltage	Balance voltage for single cell	/
	2	Current	Balance current for single cell	/
			Current consumption for single cell	≤20μA
			Maximal continuous Charging current	5A
			Maximal continuous Discharging current	5A
	3	Over charge protection	Over charge detection voltage	4.25±0.025V
			Over charge detection delay time	0.7S—1.3S
			Over charge release voltage	4.05±0.05V
	4	Over discharge protection	Over discharge detection voltage	2.4±0.08V
			Over discharge detection delay time	89—167mS
			Over discharge release voltage	3.0±0.1V
	5	Over current protection	Over current detection voltage	200±30mV
			Over current detection current	13±A
			Detection delay time	8ms—16ms
			Release condition	charge up
	6	Short protection	Detection condition	Exterior short circuit
			Detection delay time	200-500us
			Release condition	Exterior short circuit
	7	Resistance	Protection circuitry	≤30mΩ
	8	Temperature	Operating temperature range	-40～+85℃
	8	Temperature	Storage temperature range	-40～+125℃
	B+=Battery+, B-=Battery- P+=Charge+/Discharge+ P-=Charge-/Discharge-
